i have a 15 year old 700 series sidecar and would like to know if the new model 565 body will fit on my older frame? what is the max width of the 565 body, and the measurements of the mounting bolt holes, length between and across and diaganly?
thank you
The 565 has a quite different reinforced frame and the 565 fender is frame mounted, not body mounted. A different large frame step matches the wide 565 fender and wide wheel.
Lonnie
i know the frames are different. my fender is frame mounted also, i'm talking about the 565 BODY ONLY. MOUNTING TO MY FRAME... I just need the 565 dimentions?
Don't have a 565 in the shop right now. The 563 uses the same frame though.
Try 29 1/2" front to back for mount holess. 11 1/2" front mount holes and 11" rear holes and see what you get on the 700.
22' body width.
L.
